Project Description

Frame thickness : 100 mm
Height : up to 8000 mm
STC : 43-50 dB
Top supported without floor track or guide
Single door or double doors in partition
Clear anodized extruded aluminum track and frames,customized powder coated color are available
Send A Message

Recovery Ensures

Product Description

Our GreatFold movable partitions are clsssified according to their

thickness,Height&Sound Proofing Coefficient.Our”Type”Signifies

the Thickness of Partition in “MM”

  • GLS-65 Economic Partition
  • GLS-85 Standard Partition
  • GLS-100 Deluxe Partition
  • GLS-H Ultra High Partition

Glass Partition:

  • GLS-G40 Frameless Operable Glass Wall
  • GLS-G65/85 Full Frame Movable Glass Wall
  • Full Height Glass Partition Wall

Chart of Screen Internal Structure

Surface Material

Storage Style

GreatFold Technical Description Feature

1. Top hung with no floor track required
2. High acoustic ratings up to 55dB available
3. Retractable acoustic seals at top and bottom of each panel operated either by a quick release handle
4. Single or twin point suspension for central or offset stacking options
5. Variable track arrangements
6. Junction panels enable corner, three or four way abutments
7. Panel finishes include Melamine Laminate, Veneer, Vinyl, Magnetic Dry Wipe Whiteboard or

    Painted, etc
8. Optional inset pass doors, fully glazed panels and vision panels
9. Closure panel fitted with face operated telescopic “nose”

Perfect packing and 3 years warranty for panel,5 years warranty for accessories
